Commercial Rolling Steel Garage Doors

Commercial Rolling Steel Garage Doors

Overhead Doors

Overhead Door Corporation’s rolling service door product line is available with the industry’s widest array of slat profiles, curtain materials and colors.

The breadth of Overhead Door Corporation’s rolling service door product line ensures that your project specifications will be met with ease and style. Ideal for situations where sideroom and headroom are at a premium, our upward-coiling service doors fit openings up to 1500 sq. ft. (139,355 and are available with the industry’s widest array of slat profiles, curtain materials and colors, offering a virtually endless array of options to satisfy both aesthetic considerations and working requirements.

Product Details

  • Galvanized steel, stainless steel and aluminum doors in a variety of gauges, slat profiles, finishes and options
  • Standard door widths up to 30′ (9144 mm) and 28′ (8534 mm) in height, and custom door sizes up to 1500 sq. ft. (139,355
  • Rolling service doors for heavy-duty, medium-duty and light-duty applications
  • Coil-Away™ 600 Series door offers an economical solution for openings to 16′ wide and 16′ high (4877 mm and 4877 mm)
  • Stormtite™ 620 and Stormtite™ 625 Series insulated doors provide extra protection against the elements
  • Solid construction withstands windloading of 20 psf, with a higher windload option to meet requirements
  • Structural steel angle or roll-formed guide design ensures smooth curtain operation
  • Helical torsion springs designed for 20,000 cycles, with high usage option to 100,000 cycles
  • Each door is computer-designed to ensure precision manufacturing and facilitate installation
  • Computer-matched door counterbalance system and optional motor operator promote precision operation and performance


  • Roll-formed galvanized steel, stainless steel or aluminum curtains in weights from 26 to 14 gauge (not all gauges available in all materials)
  • Curved or flat slats in a range of sizes and profiles, including the C-600, a 6″ (152 mm), 1 3/8″ (35 mm) curved slat for heavy-duty applications
  • Finishes include primed and painted steel, optional powder-coated paint in 197 standard colors, or
  • colormatched to specification, as well as clear or colored anodized aluminum
  • Face of wall mounting is standard with between-jambs mounting available for medium and heavy -duty doors
  • Push-up, chain-hoist, crank or motor operation available
  • Electric motor option with an array of radio and remote controls simplifies door operation
  • Ventilated slats with perforations or fenestration extend applications to open-air environments (610 Series only)
  • Fenestrations are available on the 620 (with vision lites) and the 625 (double glazed insulated or single glazed non-insulated).
  • Weatherstripping (620 Series) and/or insulated slats (625 Series) offer additional protection against air infiltration
  • High-usage package and pedestrian pass doors available for special applications
